Shacman 6CBM Water Sprinkler Dust Suction Road Sweeper Truck

تصویر بزرگ : Shacman 6CBM Water Sprinkler Dust Suction Road Sweeper Truck

جزئیات محصول:

محل منبع:	سوئیژو، چین
نام تجاری:	CLW
گواهی:	CCC,ISO,BV,SGS
Model Number:	CLW50749uv

پرداخت:

مقدار حداقل تعداد سفارش:	1 واحد
قیمت:	negotiable
جزئیات بسته بندی:	بسته بندی برهنه
زمان تحویل:	30-35 روز پس از دریافت پیش پرداخت
شرایط پرداخت:	T/T، L/C
قابلیت ارائه:	300 واحد در ماه

مخاطب

توضیحات محصول جزئیات

Truck Chassis:	Shacman,Dongfeng,JAC,JMC,ISUZU,HOWO	مواد:	فولاد ضد زنگ
عرض جارو:	3.5 متر	هوادار:	بدون نگهداری
چراغ هشدار عقب:	بله	برس ها:	2 واحد
دفترچه راهنمای عملیات:	بله	ویدئوی عملیاتی:	بله
استفاده:	سرویس بهداشتی شهر	رنگ:	نقاشی LOGO سفارشی طبق درخواست مشتری
گارانتی:	1 سال
برجسته کردن:	6CBM Road Sweeper Truck,Shacman Road Sweeper Truck , Shacman Road Sweeper Truck

Shacman 6cbm Street Cleaning Water Sprinkler Dust Suction Road Sweeper Truck

Product Description

This equipment is made from our company according to many years of road maintenance construction experience, and combined with the actual needs of customers.It is a kind of vacuuming equipment independently developed and produced for minor repair and maintenance construction of irrigation joints and pits.The utility model has the characteristics of simple operation, high dust absorption efficiency and continuous operation.Widely used in municipal, highway, national and provincial arterial road construction dust, particle recovery operations.

Dongfeng Truck Chassis
Condition	New condition/Right hand drive/4x2
Chassis	Brand			Shacman
	Curb weight(kg)			4460 kg
	Wheelbase(mm)			3815 mm
	Dimensions(mm)			7180 x 2260 x 2680 mm
	Wheel track (front/rear) (mm)			1504/1425
	Approach/Departure angle(°)			24/13
	Axle Load(kg)			5280/4720
	Max. driving speed(km/h)			90 km/h
	Tire	Specifications		6pcs with one spare tire
		Number		8.25-16
Clutch	Reinforced diaphragm clutch
Gear box	Manual type, 6 Forwards & 1 Reverse
Cabin	Left Hand Driving, 3 Passenger Allowed
Engine	Model				Diesel Engine, 4 Cylinders
	Power(kw)/Horsepower(HP)				103 kw/140 HP
	Emission standard				Euro IV
Brakes	Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake
Steering Gear	Power steering, hydraulic steering with power assistance
Sweeping System
Tank	Garbage tank		Tank material		Stainless steel 304
			Tank volume(cbm)		4 CBM
	Water tank		Tank material		Stainless steel 304
			Tank volume(cbm)		2 CBM
Auxiliary engine	Model		ISUZU
	Power(kw)		102 kw/140HP
Brush	Quantity(pc)		2 pcs
	Working area(m)		2.7-3.2 m
Cleaning	High pressure reel		18 meters
Remarks	1, With water sprayer-bar 2, Rear vacuum cleaner 3, Blower 4, Rear LED pilot lamp 5, Self unloading box body 6, The color will be designed on basis of your requirements.

Details

Shacman 6CBM Water Sprinkler Dust Suction Road Sweeper Truck 0

Shacman 6CBM Water Sprinkler Dust Suction Road Sweeper Truck 4

Sales Service

①Pre-sales Service: Communicate with customers, analyze their needs.
②Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.

FAQ

Q1: What kinds of Sweeper Truck products I can order from your company?

A: We can supply all kinds of sweeper trucks, Vacuum sweeper truck, High pressure road sweeper truck, Normal road sweeper etc.

Q2: What is your production standard of Sweeper Truck products? Whether your Mobile Advertisement Truck can export to USA, Canada and Europen countries?

A: Our CBU Sweeper Truck is produced as per China GB local standard; We can't export CBU Sweeper Truck to those countries, but we can export super structure to those market, we exported 50 units Sweeper Truck to USA market at the beginning of 2017.

Q3: Have you supplied to Sweeper Truck any renowned companies?

A: Our group company is a regular strategic partner of some big government department and waste treatment company. We have supplied many different type Sweeper Truck for them with different chassis brand.

Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
