Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine

تصویر بزرگ : Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine

جزئیات محصول:

محل منبع:	سوئیژو، چین
نام تجاری:	CLW
گواهی:	ISO, CCC
شماره مدل:	clw5252WYYGC

پرداخت:

مقدار حداقل تعداد سفارش:	1 واحد
قیمت:	negotiable
جزئیات بسته بندی:	بسته برهنه با کشتی فله ارسال می شود
زمان تحویل:	30 روز پس از دریافت پیش پرداخت
شرایط پرداخت:	L/C، T/T، D/P، T/T، Western Union، MoneyGram، D/A
قابلیت ارائه:	300 واحد در ماه

مخاطب

توضیحات محصول جزئیات

برند کامیون:	Sinotruk Howo	Drive model:	8x4, 12-wheeler fuel tanker truck
Tank volume:	25000liters, 25000L, 25cbm, 25m3 fuel tanker truck	نوع سوخت:	کامیون تانکر سوخت دیزل / بنزین / نفت
وضعیت:	کامیون تانکر سوخت نو	نوع انتقال:	10 سرعت جلو و 2 عقب
اسب بخار:	371 اسب بخار	ماده مخزن:	فولاد کربن، فولاد کربن Q235 / فولاد ضد زنگ، فولاد کربن / فولاد رنگ‌آمیزی / آلیاژ آلومینیوم، آلیاژ آل
نام محصول:	کامیون تانکر سوخت، کامیون تحویل سوخت، کامیون تانکر سوخت، کامیون سوخت هوو	استاندارد انتشار:	یورو 2
Wheelbase:	1800+4625+1350	Specification:	11970249603025mm
Hose Reel with Filling Gun:	Optional, Length Can Be Longer as Per Request
برجسته کردن:	25m3 Oil Tanker Truck,Sinotruk HOWO Oil Tanker Truck,8x4 Fuel Delivery Truck , Sinotruk HOWO Oil Tanker Truck , 8x4 Fuel Delivery Truck

Oil tamker truck is mainly used or storage and transport oil, diesel, gasoline, kerosene, stainless steel fuel bowser etc.

Product advantages
1. Tank material: we can provide carbon steel tanks, stainless steel tanks, manganese steel tanks, aluminum tanks, steel with plastic (or rubber) tanks and plastic tanks.
2. Good welding: tank body is adopted an advanced automatic vertical welding techniques and head arc but welding technology, as well as the whole- steel forming a composite.
3. High safety: equip with active and passive emergency protection devices, to provide full closure remote manipulation of materials handing functions. Equipped separators baffle to prevent surging of liquid towards bulk head.
4. Function: The tank body is suit for loading light fuel oil, heavy oil, sulfuric acid, hydrochloric acid, nitric acid, caustic soda hydrogen peroxide, alcohol, benzene, cooking oil and so on.
5. Oil punp: gear pump, self-absorption pump, chemical pump, heavy, oil pump, stainless steel pump are optional.
6. Tank shape: shape of tank body can be designed to square round, round,Heat insulation device such as heating pipes, insulation.
7. Refueling machine: the refueling machine we use are tax controled oiling machine with accurate figure of volume, sum of money,etc.
8. Optional: reading meter for outlet and inlet,self-discharge valve at rail or side of tank body, compartment quantity according to the demand.

Specification

General Technical Parameters
Overall Dimension	11970249603025(mm)		Gross Vehicle Weight	36000(kg)
Curb Weight	11450(kg)		Loading Weight	25000(kg)
Chassis Specification
Chassis Parameters	Chassis Brand		SINOTRUK
	Cabin		Row and half, right Hand Driving
	Engine	Power	371HP
		Emission standard	EURO2
		Displacement	9726ml
		Fuel type	Diesel
	Gearbox		10 Forward & 2 Reverse Gear
	Front and Rear Axle load		9T/16T (8x4 Driving type)
	Wheel Base		1800+4625+1350(mm)
	Brake System		Pneumatic
	Steering Gear		Power Assistant
	Tire		12.00R20, 12 Pieces+one spare tire
	Maximum speed		85(km/h)
Tank Body
Shape	Monoblock Cylinder
Total Volume(m³)	25m3
Tanker Body Material	5-6mm carbon steel
Manhole Cover	∮500mm ,1 set with 1 breather valve
Bottom Valve	1 set
Discharging Valve	1 set ∮80mm discharging valve
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint
Accessories	One standard tool box

Reference photos

Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine 0

Sinotruk HOWO 12 Wheeler 25m3 Oil Tanker Truck Fuel Transportation Machine 1

Key words: Fuel bowser truck, fuel tanker truck, oil transport truck, oil truck tanker, light fuel tank truck, truck tank fuel, petrol tanker, petrol fuel tank, diesel dispensing truck, oil delivery truck, Mobile Fuel Truck, oil loading truck, oil refuelling truck, oil transport truck, oil truck tanker, light fuel tank truck, truck tank fuel, petrol tanker, petrol fuel tank, fuel bowser, diesel dispensing truck.

It can be divided into many compartments to transport different medium, which will make your transportation easy and safe.

Warranty
1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.

Spare Parts
1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.
3. Only charge cost price for customer convenience.

After Sales Service
Email & Phone call tracking for each truck on timely manners.

Shipment
Land transportation or Ship by bulk cargo ship, container, roro ship
