Heavy Duty Hydraulic Gooseneck Lowbed Flatbed Trailer 100tons

100tons Heavy Duty Hydraulic Gooseneck Lowbed Flatbed Trailer

Dimension: 16000x3300x1200mm
Top flange plate: Q345B, 25mm
Middle flange plate: Q345B, 16mm, 530mm
Bottom flange plate: Q345B, 25mm
Material: Carbon steel Q345 with 5mm thickness
Tire: 11.00R20 radial tire
Kingpin: 3.5 inch bolts type
Spring Leaft: 12 layers with 16mm leaf thickness

Accessories: Spare tire carrier, LED light, 24V light, 7 ways(7wire harness)and quick change type Receptacle, tool box, Painting( Polyurethane paint&anti-rust primer & sand blasting

It is mainly used for medium and long-distance freight transportation.
The trailer frame is beam-through structure, and the longitudinal beam adopts a straight live gooseneck type.

​Product parameters

​Reference photos

Low loader trailer is applicable to the transportation of various kinds of steel products for various mechanical equipment,
large objects, highway construction equipment, large tanks, power station equipment and machines.

The suspension design reduces the instantaneous friction and slip distance between the tire and the ground during the frequent bumpy operation of the whole vehicle, effectively reduces the friction of the tire, and prolongs the service life of the tire.
It can ensure the verticality of the axle and the traction pin, effectively eliminate the eccentric wear and gnawing of the trailer tires, and make the tires wear evenly.

Drawing:​​

​​

 Packaging & Shipping
1. Nude and waxed before delivery.
2. Bulk cargo ship & Ro-Ro ship & 40'HQ container.
