HOWO 4X4 290hp Fire Resuce Truck Emergency Rescue Truck With High Pressure Pump

تصویر بزرگ : HOWO 4X4 290hp Fire Resuce Truck Emergency Rescue Truck With High Pressure Pump

جزئیات محصول:

محل منبع:	سوئیژو، چین
نام تجاری:	CLW
گواهی:	CCC,SGS,BV
Model Number:	CLW20220FDEIUF

پرداخت:

مقدار حداقل تعداد سفارش:	1 واحد
قیمت:	negotiable
جزئیات بسته بندی:	برهنه، موم شده، کشتی فله، رو-رو
زمان تحویل:	30 روز پس از دریافت سپرده
شرایط پرداخت:	L/C، D/A، D/P، T/T، Western Union، MoneyGram
قابلیت ارائه:	500 واحد در ماه

مخاطب

توضیحات محصول جزئیات

شاسی کامیون:	دانگ فنگ، هوو، ISUZU، Shacman، CAMC، Foton	Capacity:	6cbm, 6m3, 6000L, 6cubic meters
تایپ کنید:	کامیون آتش نشانی مخزن آب، فوم، کامیون آتش نشانی پودر خشک، ماشین آتش نشانی نجات	پمپ آتش:	مارک چینی
دامنه مانیتور آتش:	≥50 متر	سرعت جریان مانیتور:	48 لیتر در ثانیه
سرعت جریان پمپ:	60 لیتر در ثانیه	فرمان:	LHD یا RHD
Usage:	Fire Fighting Truck, Emergency Rescue	Extinguishing Agents:	Water, Foam
مواد:	فولاد کربن/استیل ضد زنگ
برجسته کردن:	290hp Fire Resuce Truck,HOWO 4X4 Fire Resuce Truck,60L/s Pump Emergency Rescue Truck , HOWO 4X4 Fire Resuce Truck , 60L/s Pump Emergency Rescue Truck

Product Description

1. 9900*2500*3500 overall dimensions
2. Howo 4X4 off- load chassis with double-row cabin
3. Weichai diesel engine with 290hp
4. 10 forward and 2 reverse gear box
5. 7t front axle and 16t rear axle
6. Accessories: crew compartment, water tank (body), pump house, equipment compartments, water and foampump system, fire monitor, electronic sirens, lights and fire equipment
7. 360° rotation angle
8. Rated pressure of hydraulic system:16Mpa

Application range:
factory, terminal, oil&gas depot to insure emergency fire cases

Specifications of HOWO 4X4 fire fighting truck

General	GVW/Curb weight	14490kg/7430kg
	Rate of load	6865kg
	Overall size	990025003500
cab	Cab	Flat head, double-row, four doors, hydraulic tilt cab,2+4 seat, 4 Set of safety belt in the back seats. Manual window
Chassis	Siren control system	Yes
	Air conditioner	Yes
	Drive type	4x2 left hand drive
	Fuel type:	Diesel
	Engine manufacturer/model	WEICHAI/ WD615.87
	Power	290hp
	Displacement	9726ml
	Emission standard	Euro 2
	Engine type	six cylinder, four-stoke, water-cooled, turbocharged and intercooled, fuel direct injection pump.
	Shift box	10-speed Forwarder with 2 Reverse
	Brake	Air brake
	Wheelbase	5600mm
	No. of axle/payload	7000kg/16000kg
	Tire specification/No.	295/80R22.5/6+1
	Max speed	85km/h
	Paint color	Red paint
Special configuration	Water Tank capacity	4000L Made in high-strong carbon steel with anti-corrosion
	Foam tank capacity	2000L Made in high quality steel with anti-corrosion
	Consist of crew compartment, water tank (body), pump house, equipment compartments, water and foampump system, fire monitor, electronic sirens, lights and fire equipment.
	This truck is improved and refitted with chassis of HOWO. It is equipped with foam spraying fire system. The spacious cabin is suitable for six crews. Its internal structure reasonable and compact its foam spraying fire system could be used signally or jointly
	Atmospheric pressure pump fire pump: CB10/60 @ 1.0Mpa,Leading water time ≤ 50s, within water depth 7m
	Fire monitor Model: PL48(dual-purpose gun blisters) Water range ≥ 55m/1.0MPa , foam range: ≥ 50m/1.0MPa
Technical Data for monitor sky lifting function
Max. Working Height	18m(22m,25m,28m can be chose)	Outrigger Span	2350mm
Max. Working Radius	6.5m	Rotation Angle	360°
Max Luffing Angle of Boom	85°	Rated Pressure Of Hydraulic System	16Mpa
Max Luffing Angle of Forearm	155°	Max Oil Flow Of Hydraulic System	30L/min
Safety Performance	On and off interlock device
	Turntable indication device
	Boom and forearm interlock device
	Rotation limit device
	System does not work after power failure
	Soft leg alarm function
	Boom and forearm Angle Mechanical limit device

Reference photos

HOWO 4X4 290hp Fire Resuce Truck Emergency Rescue Truck With High Pressure Pump 0

Working Scene of water tank fire brigade truck

Equipment come with fire trucks
HOWO 4X4 290hp Fire Resuce Truck Emergency Rescue Truck With High Pressure Pump 2

Production Procedure

HOWO 4X4 290hp Fire Resuce Truck Emergency Rescue Truck With High Pressure Pump 3

HOWO 4X4 290hp Fire Resuce Truck Emergency Rescue Truck With High Pressure Pump 4

Why choose us:

Certificate: ASME, ISO, BV, SGS, CCC etc.
More than 30 independents workshops for different types of trucks
1000 sets of equipment, 25 assemble lines.
300 senior engineers and technicians and about 8000 staffs
800kinds of trucks and semi-trailers with various functions
20 years wholesale experience
Turnover 250 million and Export 20million annually
More than 100,000 trucks and semi-trailers annually.
Truck Sold to 90 countries
Long term cooperation with China leading chassis supplier DONGFENG,SINOTRUCK,FOTON,FAW,BEIBEN,ETC
We can handle production of bulk order water trucks of tender and government purchase in required time
