Dongfeng Waste Disposal 6cbm Garbage Compactor Truck ISO/CCC Q235 Carbon Steel Anti-Corrosive Sanitation Garbage Deliver

تصویر بزرگ : Dongfeng Waste Disposal 6cbm Garbage Compactor Truck ISO/CCC Q235 Carbon Steel Anti-Corrosive Sanitation Garbage Deliver

جزئیات محصول:

محل منبع:	سوئیژو، چین
نام تجاری:	CLW
گواهی:	CCC,ISO,
Model Number:	CLW55IDK

پرداخت:

مقدار حداقل تعداد سفارش:	1 واحد
قیمت:	negotiable
جزئیات بسته بندی:	بسته بندی برهنه، رو-رو، کشتی فله
زمان تحویل:	20-30 روز
شرایط پرداخت:	L/C، T/T، D/P، D/A، Western Union،، MoneyGram
قابلیت ارائه:	500 واحد در ماه

مخاطب

توضیحات محصول جزئیات

Brand:	FOTON, ISUZU, Dongfeng, HOWO, JAC, JMC, SHACMAN,FAW	Function:	Garbage compactor, waste removal
مواد:	کربن فولاد Q235B	ضخامت:	سمت 3 میلی متر و پایین 4 میلی متر
Tank volume:	6cbm/6000Liters/5tons	پایه چرخ:	3308 میلی متر
اسب بخار:	115 اسب بخار	پمپ هیدرولیک:	برند معروف چینی
سیستم کنترل:	سیستم عامل برند زیمنس	گارانتی:	1 سال
کنترل کنید:	کنترل دستی	Logo&painting:	Customized
برجسته کردن:	ISO/CCC Garbage Compactor Truck

Product Descriptions:

1) Tank material:Q235 Carbon steel, anti-corrosive
2) Components of garbage trcuk: hermitical garbage box, hydraulic system and operating system
3) Ways of control: Manual control and Automatic control
4)Load operation time: less than 30 seconds
5) Unloading operation time : less than 45 seconds;
6) Optional rear flip mechanism:
* Hanging iron barrel type turning mechanism
*Swing arm type turning mechanism
*Semi-sealed garbage bucket/dustpan type turning mechanism
*Fully sealed garbage bucket turning mechanism

Key Features:

---- Dongfeng chassis, perfect performance
---- YUCHAI engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Compression body capacity from 3 to 22 Cublic Meter.
---- Easy operation and easy maintenance.

---- Various types of refuse container lifter are available.

Product Specifications

Truck Chassis Specification
Chassis model		Dongfeng
Cab		single row cab
Driving Type		4*2 Left hand driving
Max Speed (km/h)		110
Overall dimension(mm)		5875×1882×2225
GVW( kg)		4290
Mass in working order ( kg)		2390
Wheelbase(mm)		3308
F/R overhang (mm)		1061/1506
Approach/Departure Angel		24/16
Tire		7.00R16 6PR
Clutch		Single-plate dry diaphragm spring clutch
Steering		Hydraulic steering with power assistance
Gear box		6 Forwards & 1 Reverse
Bridge	Front axle	2.2T
	Rear axle	3.5T
Enging	Model	YC4FA115-50
	Fuel Type	Diesel fuel
	Type	Water-cooled four-stroke,, direct injection, turbocharged
	Exhaust(ml)	2999
Braking system	Service Brake	Compressed air brake
	Park Brake	Spring energy
	Auxiliary brake	engine exhaust brake
Eletric system		24v

Upper-Body specification
Material of tank		Material : Q235,Thickness :3(mm) side /4(mm) rear
Dirty tank volume		6cbm/6000Liters/6M3/5tons
Filler volume		500L
Filing time(s)		8~10s
Filling cycle time(s)		50~60s/once
Discharge type		Rear Discharging
Time for Discharging		30-40S
Hydraulic pressure		16Mpa
Controlling way		Manualy and electrical control

Reference photos

Dongfeng Waste Disposal 6cbm Garbage Compactor Truck ISO/CCC Q235 Carbon Steel Anti-Corrosive Sanitation Garbage Deliver 0

Diagram of compactor garbage truck

Dongfeng Waste Disposal 6cbm Garbage Compactor Truck ISO/CCC Q235 Carbon Steel Anti-Corrosive Sanitation Garbage Deliver 1

Main parts of garbage truck

Dongfeng Waste Disposal 6cbm Garbage Compactor Truck ISO/CCC Q235 Carbon Steel Anti-Corrosive Sanitation Garbage Deliver 2

Factory overview

Dongfeng Waste Disposal 6cbm Garbage Compactor Truck ISO/CCC Q235 Carbon Steel Anti-Corrosive Sanitation Garbage Deliver 3

FAQ

Q1: What kinds of garbage trucks I can order from your company?

A: There are various sizes and types of garbage trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.

Q2: Have you supplied garbage truck to any overseas companies?

A: Yes,with need of garbage waste transport,we offered garbage trucks to many Africa and south-east Asian countries.

Q3 What about warranty?

A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?

A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.

Warranty

1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.

Spare Parts

1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.

3. Only charge cost price for customer convenience.

Shipment

Land transportation or Ship by bulk cargo ship, container, roro ship
