Dongfeng 5m3/5,000 Liters Self Compressed Waste Removal Vehicles

تصویر بزرگ : Dongfeng 5m3/5,000 Liters Self Compressed Waste Removal Vehicles

جزئیات محصول:

محل منبع:	سوئیژو، چین
نام تجاری:	CLW
گواهی:	CCC,ISO,
Model Number:	CLW521O85F

پرداخت:

مقدار حداقل تعداد سفارش:	1 واحد
قیمت:	negotiable
جزئیات بسته بندی:	بسته بندی برهنه، رو-رو، کشتی فله
زمان تحویل:	20-30 روز
شرایط پرداخت:	L/C، T/T، D/P، D/A، Western Union،، MoneyGram
قابلیت ارائه:	500 واحد در ماه

مخاطب

توضیحات محصول جزئیات

Brand:	FOTON, ISUZU, Dongfeng, HOWO, JAC, JMC, SHACMAN,FAW	Function:	Garbage compactor, waste removal
مواد:	کربن فولاد Q235B	ضخامت:	سمت 3 میلی متر و پایین 4 میلی متر
Tank volume:	5cbm/5000Liters/3tons	پایه چرخ:	3308 میلی متر
اسب بخار:	108 اسب بخار	پمپ هیدرولیک:	برند معروف چینی
سیستم کنترل:	سیستم عامل برند زیمنس	گارانتی:	1 سال
Control:	Both manual and electric control
برجسته کردن:	Dongfeng Self Compressed Waste Removal Vehicles,5000l Self Compressed Waste Removal Vehicles,5m3 Self Compressed Waste Removal Vehicles , 5000l Self Compressed Waste Removal Vehicles , 5m3 Self Compressed Waste Removal Vehicles

Dongfeng 5m3/5,000liters Self Compressed Waste Removal Vehicles

Product Descriptions

Widely used, support customized
Heavy load , simple operation
Plate thickening , fully function
High-quality Q345 manganese steel of WISCO, with three sides and four bottoms, curved box body, which has good force, no deformation, and larger loading capacity.
Box body adopts automatic welding (full welding), which does not scrape dust, does not leak, beautiful and durable.
Double sewage collection tank design, sealed treatment, eliminate secondary pollution, sewage tank is installed with a unique sewage valve, reliable sealing, not easy to block.

Product Specifications

Truck Chassis Specification
Chassis model		EQ1040G47DJAC
Cab		Dongfeng single row cab
Driving Type		4*2 Left or right hand driving
Max Speed (km/h)		99
Overall dimension(mm)		5840×1980×2170
GVW( kg)		4495
Mass in working order ( kg)		2370
Wheelbase(mm)		3308
F/R overhang (mm)		1100/1432
F/R track (mm)		1438/1486
Approach/Departure Angel		17/14
Tire		6.50R16,7.00R16(6+1 spare)
Clutch		Single-plate dry diaphragm spring clutch
Steering		Hydraulic steering with power assistance
Gear box		5-speed
Bridge	Front axle	2T
	Rear axle	3T
Enging	Model	CYQD32T(Chaoyang)
	Fuel Type	Diesel fuel
	Type	Water-cooled four-stroke,, direct injection, turbocharged
	Exhaust(ml)	3153
Braking system	Service Brake	Compressed air brake
	Park Brake	Spring energy
	Auxiliary brake	engine exhaust brake
Eletric system		24v

Upper-Body specification
Material of tank		Material : Q235,Thickness :3(mm) side /4(mm) rear
Dirty tank volume		5cbm/5000Liters/5M3/3tons
Filler volume		500L
Filing time(s)		8~10s
Filling cycle time(s)		50~60s/once
Discharge type		Rear Discharging
Time for Discharging		30-40S
Hydraulic pressure		16Mpa
Controlling way		Manualy and electrical control

Diagram of compactor garbage truck

Dongfeng 5m3/5,000 Liters Self Compressed Waste Removal Vehicles 0

Main parts of garbage truck

Dongfeng 5m3/5,000 Liters Self Compressed Waste Removal Vehicles 1

Compactor Carbage Truck Production Process

Dongfeng 5m3/5,000 Liters Self Compressed Waste Removal Vehicles 2

Factory overview

Dongfeng 5m3/5,000 Liters Self Compressed Waste Removal Vehicles 3

Our Service

Quick feedback to solve your questions
Professional engineering and production team
Related Accessories and spare parts offered,no future worries
Regular customer after-sale visiting
Free technical staff training and guidance
Reasonable price and good quality
Quick delivery and shipment

FAQ

Q1: What kinds of garbage trucks I can order from your company?

A: There are various sizes and types of garbage trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.

Q2: Have you supplied garbage truck to any overseas companies?

A: Yes,with need of garbage waste transport,we offered garbage trucks to many Africa and south-east Asian countries.

Q3 What about warranty?

A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?

A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
