HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD
خانه محصولاتکامیون تانکر گاز مایع

4Axles 8x4 Howo LPG Bobtail Truck LPG Delivery Truck Large Capacity 35m3

چین HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD گواهینامه ها
چین HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD گواهینامه ها
چت IM آنلاین در حال حاضر

4Axles 8x4 Howo LPG Bobtail Truck LPG Delivery Truck Large Capacity 35m3

4Axles 8x4 Howo LPG Bobtail Truck LPG Delivery Truck Large Capacity 35m3
4Axles 8x4 Howo LPG Bobtail Truck LPG Delivery Truck Large Capacity 35m3 4Axles 8x4 Howo LPG Bobtail Truck LPG Delivery Truck Large Capacity 35m3 4Axles 8x4 Howo LPG Bobtail Truck LPG Delivery Truck Large Capacity 35m3 4Axles 8x4 Howo LPG Bobtail Truck LPG Delivery Truck Large Capacity 35m3

تصویر بزرگ :  4Axles 8x4 Howo LPG Bobtail Truck LPG Delivery Truck Large Capacity 35m3

جزئیات محصول:

محل منبع: سوئیژو، چین
نام تجاری: CLW
گواهی: GB150, ASME
Model Number: CLW1YCDJ4

پرداخت:

مقدار حداقل تعداد سفارش: 1 واحد
قیمت: negotiable
جزئیات بسته بندی: بسته برهنه با کشتی فله ارسال می شود
زمان تحویل: 30 روز پس از دریافت پیش پرداخت
شرایط پرداخت: L/C، T/T، D/P، T/T، Western Union، MoneyGram، D/A
قابلیت ارائه: 300 واحد در ماه
توضیحات محصول جزئیات
Truck brand: HOWO,DONGFENG,JAC,ISUZU LPG Bobtail Trucks Material: Q345R LPG Bobtail Trucks
اندازه مخزن: سفارشی Loading weight: 2-20tonns (Customized)
Engine: Diesel engine MC11.36-40 Type اسب بخار: 365 اسب بخار
purpose: Skid Station Refilling,cylinder filling LPG Bobtail Trucks فشار طراحی: 1.61 مگا پاسکال 16.1 بار
Drive wheel: 4x2, 6x4, 8x4, 2Axles, 3Axles, 4Axles ذخیره سازی: LPG، روغن، آب، LPG پروپان پنتان، گاز
Emmission: Euro2/3/4/5, Euro III/Euro IV/ EuroV LPG Bobtail Trucks Name: LPG Bobtail Trucks, LPG Bobtail Trucks GAS FILLING TRUCK / lpg cylinder filling truck, gas refuel truck
رنگ: سفارشی
برجسته کردن:

35m3 LPG Bobtail Truck,8x4 Howo LPG Bobtail Truck

,

8x4 Howo LPG Bobtail Truck

4Axles 8x4 Howo Large Capacity 35m3 LPG Bobtail Truck LPG Delivery Truck

8x4 Howo Large Capacity 35m3 LPG Bobtail Truck

  • LPG bobtail truck capacity: from 5cbm to 37.2cbm
  • tank meaterial:Q345R Q370R Q420R SA516
  • tank production flow:cuttings-bending plate-submerged arc welding-assembly-non destructive testing-heat treatment- hydraulic test- sand blasting-painting
  • Refiling System of LPG Bobtail Trucks : 2" Flowmeter or intelligent filling dispenser machine,2" Corken or Chinese brand Pump,15meters Filling Hose Reel,filling nozzle,radiator,hydraulic oil box
  • Truck Spec of LPG Bobtail Trucks : Sinotruk diesel Engine MC11.36-40 Type 365hp, 80R22.5 (12 pcs with one spare).





Specification

Item No. Parameters
Overall Dimension 11735x2496x3230mm
Driving Model left hand drive
Gross Vehicle Weight 31000 kg
Curb Weight 11280kg
Payload 19720kg
Wheel Base 1950+4600+1400mm
Front/rear Tread 1540/2245 mm
Approach/Departure Angle 15/20 degree
Front Axle 6500
Rear Axle 7000/17500(Heavy duty design)
Engine MC11.36-40,4-stroke direct injection,6-cylinder in-line with water cooling,turbo-charging and inner cooling
Engine horsepower 365HP EURO4
Displacement 10518mL (Diesel)
Max Driving Speed 101 km/h
Tire 80R22.5 (12 pcs with one spare)
LPG tank
Volume: 35,000Liters/35,000liters
Tank material: Q345R
Tank diameter: 2400mm
Tank thickness: 12mm
End plate 14mm
Tank length: Customized
Gas phase DN50 or according to customer request
Liquid Phase DN80 or according to customer request
Filling gas Propane(LPG)
Design Pressure: 1.61Mpa
Accessory
LPG Pump 1 pc,Chinese brand
radiator 1 pc
Volume flow meter 1 pc,English remarks with printer for receipt,Chinese brand
Filling hose with filling nozzle 15M
Level Gauge Rochester Float Ball type/located at side or rear of lpg tanker
Safety Valve 1,DN80
Tool and Valve Box 1
Thermometer 1
Pressure Gauge 1
Emergency Valve 1
Fender Steel
Fire Extinguisher Holder 2
Exhaust shaft At the front of truck for safety



After sales service



Before purchasing:

1- Quick reply on customers' inquiry;

2- Professional suggestion on truck choice according to different countries.

3- Details quotation with spec.and reasonable price.

4- Welcome to visit our company before purchasing.



After purchasing:

1- Production pictures and video updated every week.

2- Customer can visit factory after truck completion or arrange third party inspection.



After-sales service:

1- English Operation Video

2- Free operation and technical train at factory but not include accommodation

3- Spare parts supplied at factory price whenever needed.

4- Engineers can be sent to your country and offer local engineering support and train.





FAQ



Q1: What kinds of propane truck I can order from your company?

A: We can supply propane truck from 5000Liters to 35000liters. Pls contact with us for more technical details discussion.



Q2: What is your production standard of propane truck? Whether your propane truck exported to others countries?

A: propane truck is produced strictly according to GB150.1~4,we supplied lpg bobtail to AA RANO,Hass Petroluem,NIPCO and so on.



Q3: What's the difference between your company and other chinese supplier?

A: As the top manufacturer of lpg trucks and products for more than 15 years,our sales are more professional and they will offer you suggestion. And we took part in lpg summit in Africa and Asia every year.



Our factory:
