Zimbabwe LPG Gas Storage Tank LPG Gas Filling Tank 30tons 60000liters

تصویر بزرگ : Zimbabwe LPG Gas Storage Tank LPG Gas Filling Tank 30tons 60000liters

جزئیات محصول:

محل منبع:	سوئیژو، چین
نام تجاری:	CLW
گواهی:	ASME,CCC,SGS,BV
Model Number:	CLW530Y5D6

پرداخت:

مقدار حداقل تعداد سفارش:	1 واحد
قیمت:	negotiable
جزئیات بسته بندی:	بسته برهنه، کشتی فله، رول رول
زمان تحویل:	30 ~ 30 روز پس از دریافت سپرده
شرایط پرداخت:	L/C ، T/T ، Western Union ، MoneyGram ، D/A ، D/P
قابلیت ارائه:	500 واحد در ماه

مخاطب

توضیحات محصول جزئیات

مواد تانکر:	Q345R، SA516	ضخامت پایان ظرف:	16 میلی متر
بدنه تانک:	14 میلی متر	قطر مخزن:	DN2700mm،
اندازه:	30 تن، 60 مترمکعب، 60000 لیتر، 30 تن، 30 متر، 60 سانتی متر متر مربع	فشار طراحی:	1.77 مگاپاسکال / 17.7 بار، یا همانطور که لازم است
لوازم جانبی تانک:	شیر ایمنی، شیر قطع، گیج سطح، فشارسنج	سطح سنج:	Rego Rotogage یا نوع مغناطیسی
رنگ:	سفارشی
برجسته کردن:	LPG Gas Filling Tank 30tons,60000liters LPG Gas Filling Tank , 60000liters LPG Gas Filling Tank

Zimbabwe 30tons 60000liters LPG Gas Storage Tank LPG Gas Filling Tank

Product Description

1. LPG Tank Storage Content: LPG Gas, Propane, Butane, Liquid Ammonia, etc

2. Tank Design Standard: GB150-2013, ASME Standard with U STAMP.
3. Test: 100% Radiaographic Test, Magnetic Power Test, Water Pressure.

4. LPG storage tank capacity: 5-200m3 (Customized)

5. LPG storage tank material: Q345R Q370R SA516 SA517

6. Corrosion Resistance Painting: 2 Times

7. Surface Painting: 1 Time (color is customized)

60 CBM LPG TANK DIMENSIONS
Volume of Tank		60 CBM
Filling Weight		23940 kg
Tank Weight		12750 kg
Thickness of Body (mm)		14 mm
Thickness of Endplate (mm)		16 mm
Tank Diameter (mm)		2700 mm
External Dimensions (mm) (length x width x height)		10962x 2728x 3318 mm
Material of Tank and Main Pressure Parts		Carbon Steel Q345R
Filling Medium		Liquefied Petroleum Gas
Design Pressure		1.77 MPa / 17.7 Bar
Water Test Pressure		2.22 Mpa / 22.2 Bar
Corrosion Allowance		1 mm
Medium Density		500 kg/ cbm
Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China.
Main parts of LPG Tank
Item	Specification		Quantity
Discharge Pipe	DN80		1
Inflow Pipe	DN80		1
Gas phase balance pipes	DN50		2
Drain Hole	DN50		1
Manhole	DN450		1
Air-out Pipe	DN50		1
Safety Valve Pipe	DN100		1
Safety Accessories (Included in the quotation): Cut-off Valve, Non return Valve, Safety Valve, Magnetic Liquid level meter, Pressure gauge, Temperature Gauge.

Our Factory

Zimbabwe LPG Gas Storage Tank LPG Gas Filling Tank 30tons 60000liters 0

Our Service

Quick feedback to solve your questions
Professional engineering and production team
Related Accessories and spare parts offered,no future worries
Regular customer after-sale visiting
Free technical staff training and guidance
Reasonable price and good quality
Quick delivery and shipment

FAQ

Q1: What kinds of LPG products I can order from your company?

A: We specialize in producing 5CBM to 200CBM LPG above ground storage tanker, 5CBM to 120CBM LPG underground storage tank, 5CBM to 38.5CBM LPG tank truck, 5CBM to 25.5CBM LPG dispenser truck/LPG bobtail truck, 40CBM to 61.9CBM LPG semi trailer and 5CBM to 50CBM LPG Skid Station/LPG mobile filling station etc. Please feel free to contact us for details.

Q2: What is your production standard of LPG products? Can you manufacture your products under ASME standard?

A: Usually our LPG products adopts GB-150/China standard, there ASME standard for optional. Yes, we can do ASME standard and our ASME standard as per DIV 01 SEC VIII.

Q3: Have you supplied LPG products to any renowned companies?

A: Our group company is a regular strategic partner of some big gas companies. We have supplied many storage tanks and semi trailer for them with different sizes,such as ENOC,AARANO,NIPCO,LAKEGAS...The biggest size tank we ever provided is 200m3 LPG storage tanks,.

Q4: What about warranty?

A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?

A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
