Dongfeng Huashen 4x2 9cbm Garbage Compactor Truck For Sanitation Service

تصویر بزرگ : Dongfeng Huashen 4x2 9cbm Garbage Compactor Truck For Sanitation Service

جزئیات محصول:

محل منبع:	سوئیژو، چین
نام تجاری:	CLW
گواهی:	CCC,ISO,
Model Number:	CLW5101

پرداخت:

مقدار حداقل تعداد سفارش:	1 واحد
قیمت:	negotiable
جزئیات بسته بندی:	بسته بندی برهنه، رو-رو، کشتی فله
زمان تحویل:	20-30 روز
شرایط پرداخت:	L/C، T/T، D/P، D/A، Western Union،، MoneyGram
قابلیت ارائه:	500 واحد در ماه

مخاطب

توضیحات محصول جزئیات

Brand:	FOTON, ISUZU, Dongfeng, HOWO, JAC, JMC, SHACMAN,FAW	Function:	Garbage compactor, waste removal
مواد:	کربن فولاد Q235B	Thickness:	Side 4 mm and Bottom 4 mm
Tank volume:	9cbm/9000Liters/7tons	پایه چرخ:	3950 میلی متر
اسب بخار:	140 اسب بخار	پمپ هیدرولیک:	برند معروف چینی
سیستم کنترل:	سیستم عامل برند زیمنس	گارانتی:	1 سال
Control:	Both manual and electric control
برجسته کردن:	9cbm Garbage Compactor Truck,Dongfeng Huashen 4x2 Garbage Compactor Truck,Dongfeng Huashen 4x2 Waste Removal Truck , Dongfeng Huashen 4x2 Garbage Compactor Truck , Dongfeng Huashen 4x2 Waste Removal Truck

Dongfeng Huashen 4x2 9cbm 9000liters garbage compactor truck waste removal truck for sanitation services

Product Descriptions

1. Making garbage collection simple: change the dirty appearance of the city and eliminate the secondary pollution;

2. High compression ratio and large loading capacity which is 2 times larger than usual garbage truck;

3. Easy Full Automatic Operation: electrical control system for loading and unloading operations.

4. One Person Operation: Reducing sanitation work, greatly improves the working efficiency.

5. Double Operation System: electrical control system and manual operation greatly improves the vehicle usage rate.

Product Specifications

Truck Chassis Specification
Chassis model		CLW5
Cab		Dongfeng single row cab
Driving Type		4*2 Left or right hand driving
Max Speed (km/h)		100
Overall dimension(mm)		7465×2270×2800
GVW( kg)		12200
Mass in working order ( kg)		4460
Wheelbase(mm)		3950
F/R track base (mm)		1569/1530
F/R overhang (mm)		1068/1997
Approach/Departure Angel		22/25
Tire		8.25R20 6+1 pcs
Clutch		Single-plate dry diaphragm spring clutch
Steering		Hydraulic steering with power assistance
Gear box		6-speed
Bridge	Front axle	3T
	Rear axle	6T
Enging	Model	YC4E140-33 140hp
	Fuel Type	Diesel fuel
	Type	Water-cooled four-stroke, direct injection, turbocharged
	Exhaust(ml)	4257
	Max output power/rotate speed (hp/rpm )	140/2800
Braking system	Service Brake	Compressed air brake
	Park Brake	Spring energy
	Auxiliary brake	engine exhaust brake
Eletric system		24v

Upper-Body specification
Material of tank		Material : Q235,Thickness :4(mm) side /4(mm) rear
Dirty tank volume		9cbm/9000Liters/9M3/7tons
Filler volume		500L
Filing time(s)		8~10s
Filling cycle time(s)		50~60s/once
Discharge type		Rear Discharging
Time for Discharging		30-40S
Hydraulic pressure		16Mpa
Controlling way		Manualy and electrical control

Reference photos

Dongfeng Huashen 4x2 9cbm Garbage Compactor Truck For Sanitation Service 0

Diagram of compactor garbage truck

Dongfeng Huashen 4x2 9cbm Garbage Compactor Truck For Sanitation Service 4

Main parts of garbage truck

Dongfeng Huashen 4x2 9cbm Garbage Compactor Truck For Sanitation Service 5

Compactor Carbage Truck Production Process

Dongfeng Huashen 4x2 9cbm Garbage Compactor Truck For Sanitation Service 6

Factory overview

Dongfeng Huashen 4x2 9cbm Garbage Compactor Truck For Sanitation Service 8

Our Service

Quick feedback to solve your questions
Professional engineering and production team
Related Accessories and spare parts offered,no future worries
Regular customer after-sale visiting
Free technical staff training and guidance
Reasonable price and good quality
Quick delivery and shipment

FAQ

Q1: What kinds of garbage trucks I can order from your company?

A: There are various sizes and types of garbage trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.

Q2: Have you supplied garbage truck to any overseas companies?

A: Yes,with need of garbage waste transport,we offered garbage trucks to many Africa and south-east Asian countries.

Q3 What about warranty?

A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?

A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.

Warranty

1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.

Spare Parts

1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.

3. Only charge cost price for customer convenience.

Shipment

Land transportation or Ship by bulk cargo ship, container, roro ship
