GB-150 Standard 30T Q345R SA516 LPG Bulk Storage Tank

تصویر بزرگ : GB-150 Standard 30T Q345R SA516 LPG Bulk Storage Tank

جزئیات محصول:

محل منبع:	چین
نام تجاری:	CLW
گواهی:	CCC ISO ASME
شماره مدل:	CLW3656

پرداخت:

مقدار حداقل تعداد سفارش:	1 واحد
قیمت:	18,890-25,850usd
جزئیات بسته بندی:	بسته برهنه
زمان تحویل:	ظرف 30 روز پس از دریافت پیش پرداخت
شرایط پرداخت:	L/C، T/T
قابلیت ارائه:	200 واحد در ماه

مخاطب

توضیحات محصول جزئیات

خدمات پس از فروش ارائه شده است:	تامین قطعات یدکی و پشتیبانی مهندسی	حجم تانکر:	60CBM/60000Liters/30MT/30ton
ماده مخزن:	Q345R/SA516	مواد بارگیری:	پروپان/گاز نفتی مایع/LPG
فشار طراحی:	1.77MPa	چگالی متوسط:	420 کیلوگرم در متر³ 450 کیلوگرم در متر³ 460 کیلوگرم در متر³ 480 کیلوگرم در متر³ 500 کیلوگرم در متر³
تست خواص مکانیکی:	تست کشش، استحکام، ضربه	ضخامت پوسته و صفحه انتهایی:	14-16 میلی متر
وضعیت:	جدید چاپ شده	رنگ:	مشتریان
استفاده کنید:	LPG، LPG / پروپان	گارانتی:	1 سال
برجسته کردن:	SA516 LPG Bulk Storage Tank,Q345R LPG Bulk Storage Tank,30T LPG Gas Filling Station , Q345R LPG Bulk Storage Tank , 30T LPG Gas Filling Station

30tons LPG Bulk Storage Tank 60,000liters LPG Gas Filling Station LP Gas plant

Product Description

1. Storage medium of LPG Bulk Storage Tank : LPG, Liquid ammoina,Dimethyl ether,Iso-butane,Pentane and etc.

2. Available tank capacity of LPG Bulk Storage Tank: 5m³~200m³,2ton~100tons

3. Manufacturing standards of LPG Bulk Storage Tank: GB-150, ASME VIII Division I U STAMP, CCC, ISO9001 : 2008

Product Specification

Product Description:

60000 Liter Bulk LPG Propane Butane Storage Tank LPG Gas Tanks for Sale in Africa

The liquefied petroleum gas storage tank (LPG Tank) is a pressure vessel for storing liquefied petroleum gas, and is mainly used in lpg gas storage stations and chemical enterprises.

Installation method: above ground and underground
Maximum allowable working pressure: 1.82MPa
Model specifications: 5m3 ~ 200m3
OEM AVAILABLE
Quality Assurance
Intelligent production mode
Leading the industry
Fast delivery
Every detail is strictly checked

1. LPG Tank Storage Content: LPG Gas, Propane, Butane, Liquid Ammonia, etc
2. Tank Design Standard: GB150-2013, ASME Standard with U STAMP.
3. Test: 100% Radiaographic Test, Magnetic Power Test, Water Pressure.

Product Specifications

Technical Specification
Item	Name		Unit	Parameter
1	Product model		/	LPG storage tank
2	Vessel type		/	On the ground
3	Tank Volume		m3	60
4	Filling medium		/	LPG / propane gas
5	Filling coefficient		Kg/ m³	420/560
6	Tanker material		/	Q345R
7	Overall dimension		mm	1096227283318
8	Tank inner diameter		mm	2700
9	Thickness	End plates	mm	16
		Shell body	mm	14
10	Curb weight		kg	12750
11	Filling medium weight		kg	23940
12	Corrosion allowance		mm	1
13	design pressure		Mpa	1.71
14	Hydrostatic test pressure		MPa	2.22
15	Designing temperature		°C	-19~50
16	Produce Manufacturing standards		/	GB150-20
17	Certification		/	ISO 9001-2015
Production process control			1. Steel Plate Cutting &Rolling
			2. Tanker Body Welding
			3. X-ray Welding Seam Detection
			4. Whole Tanker Heat Treatment
			5. Rust, Sand Blasting, Puttying
			6. Water Pressure Test
			7. Painting: primer, finish, lacquer

Reference photos

GB-150 Standard 30T Q345R SA516 LPG Bulk Storage Tank 2

Tank diagram

GB-150 Standard 30T Q345R SA516 LPG Bulk Storage Tank 3

Tank workshop

GB-150 Standard 30T Q345R SA516 LPG Bulk Storage Tank 4

Other LPG tank/gas plant details

GB-150 Standard 30T Q345R SA516 LPG Bulk Storage Tank 5

Factory overview

GB-150 Standard 30T Q345R SA516 LPG Bulk Storage Tank 7

Sales Service

① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.

FAQ

Q1: What kinds of LPG products I can order from your company?
A: We specialize in producing 5CBM to 200CBM LPG above ground storage tanker, 5CBM to 120CBM LPG underground storage tanker, 5CBM to 38.5CBM LPG tank truck, 5CBM to 25.5CBM LPG dispenser truck/LPG bobtail truck, 40CBM to 61.9CBM LPG semi trailer and 5CBM to 50CBM LPG Skid Station/LPG mobile filling station etc. Any interests you can feel to contact us for details. Many Thanks.

Q2: What is your production standard of LPG products? Can you manufacture your products under ASME standard?
A: Usually our LPG products adopts GB-150/China standard, there ASME standard for optional. Yes, we can do ASME standard and our ASME standard as per DIV 01 SEC VIII.

Q3: Have you supplied LPG products to any renowned companies?
A: Our group company is a regular strategic partner of some big gas companies. We have supplied many storage tanks and semi trailer for them with different sizes. The biggest size tank we ever provided is 200m3 high pressure LPG storage tank

Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!

Warranty

1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.

Spare Parts

1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.
3. Only charge cost price for customer convenience.
