FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments

چین HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD گواهینامه ها
چین HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD گواهینامه ها
چت IM آنلاین در حال حاضر

FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments

FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments
FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments

تصویر بزرگ :  FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments

جزئیات محصول:

محل منبع: سوئیژو، هوبی
نام تجاری: CLW
گواهی: ISO9001, CCC, BV, SGS
شماره مدل: CLW20210612

پرداخت:

مقدار حداقل تعداد سفارش: 1 واحد
قیمت: Negotiated
جزئیات بسته بندی: قبل از حمل، برهنه یا موی شده
زمان تحویل: 30-35 روز پس از دریافت سپرده
شرایط پرداخت: L/C، D/A، D/P، T/T، Western Union، MoneyGram
قابلیت ارائه: 500 واحد در ماه
توضیحات محصول جزئیات
مواد تانکر: فولاد کربن، فولاد ضد زنگ، آلیاژ آلومینیوم محور: FUWA، BPW، L1، نام تجاری
بارگذاری محور: 13 تن یا 16 تن نفتکش: 42 متر مکعب 42 متر مکعب 42000 لیتر
محفظه: 2 3 4 5 6 محفظه محور جلو: 13 تن، یا 16 تن، قابل حمل
تعلیق: جلو: کیسه هوا، عقب: سیستم تعلیق مکانیکی. حمل: سوخت، نفت، گازوئیل، بنزین، بنزین
برجسته کردن:

42cbm Fuel Tank Trailer,FUWA Axle Fuel Tank Trailer,42cbm Tank Semi Trailer

,

FUWA Axle Fuel Tank Trailer

,

42cbm Tank Semi Trailer

3 Axle 42000L 42M3 42CBM Fuel Tank Trailer Oil Tanker truck Semi trailer with 3 compartments



Description:
** Tank material could be carbon steel, stainless steel, alluminum...
** It can be divided into many compartments to load different types of fuels.
** BPW axles, JOST kingpin, JOST landing gears, Air suspension, ABS.
** Heat preservation of rock cotton or polyurethane foaming, Heating system.
** Bottom loading system can be equipped: API connections, over-fill detection system , vapor recovery vent, vapor recovery adaptors & dust cap, pneumatic control, bottom emergent valve...
** Tube or tubeless tyres, off-road single tyre for bad roads.

product Specification



Main Dimensions
Overall Length 11240mm
Overall Height 2800mm
Tare Weight 11500KGS
Loading Capacity 42m3
Photo only for reference, final product can be made according to exact requirements
Tank Body
Shape Mono block Cylinder
Total Volume(m3) 42CBM
Tanker Body Material 6mm steel / Q235 high tensile strength steel
End plate 6mm steel sheet/Q235 high tensile strength steel
Manhole cover Aluminum alloy API manhole cover, ∮500mm ,2 sets with 2 breather valve
Bottom Valve 1-2 sets of Aluminum API Pneumatic Bottom Valve
Discharging valve 2-4 set ∮100mm discharging valves
Discharging Pipe 4”rubber hose, 2 pcs, 6m long
Chassis
Main Beams Special design I beam, connected by bolts and nuts with tanker body, removable from tanker body for separate transportation;
Axle 3 axles
BPW or FUWA 13 Ton
Landing Gear JOST brand Two-speed, manual operating, heavy duty landing gear
King Pin JOST brand 2” bolt-in king pin
Suspension German design heavy duty mechanical suspension
Pneumatic Braking System WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks.
Wheel rim 8.25R22.5 wheel rim, 13 pieces
Tire 11R22.5 tubeless tire with one spare tire, 13 pieces
Painting Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Accessories One standard tool box




3 Axle 42000L 42M3 42CBM Fuel Tank Trailer Oil Tanker truck Semi trailer with 3 compartments

FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments 0FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments 1FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments 2FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments 3FUWA Axle 42cbm Fuel Tank Trailer With 3 Compartments 4

Warranty



1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.



FAQ



Q: Can I buy a sample of your product for testing?

A. Yes, that's fine. Our MOQ is 1set.



Q: What's about the payment?

A: 40% deposit by T/T before order,balanced by T/T before delivery.



Q: How about quality of your factory product ?

A: Our product quality is ahead of other manufacturers in the industry. We have advanced production equipment ,skilled workers and perfect mangement quality. So the quality is under control. Our products are certificated by ISO 9001:2008,CCC and BV, and many trucks passed SGS inspection .


Q: How do you gurantee the quality of the product?

A: Don't worry, my dear client. Any one of you is very important to us. So we will do inspect all of the goods before shipment. And we had joined the trade credit insurance system. If the product received has quality problems, Alibaba will return the advance payment back to you.

Q: Why do you choose us?

A: We are self-produced and self-selling manufacturer and we have more than 15 years of production experience, our products have been sold all over the world.

Q: What about your after-sale service?
A: We offer 1 year after-sale service. We can supply the spare parts at factory price all the time.



Q: Can we visit your factory before purchasing?
A: We welcome you to visit our factory any time and we will show you our production line .
