Silent 25kw Diesel Generator Set Powered by Cummins/Deutz/Yangdong Engines Standby Use 25kVA-300kVA Electric Genset
Product Description
1.Oil and fuel filter fitted,water separator
2.Lube-oil drain valve fitted
3.Electric Starter Charge motor 24 VD.C
4.Water-cooled
5.Base frame with 8 hour daily fuel tank
6.Auto start
7.Optional soundproof and weatherproof canopy
8.3 pole MCCB Delixi breaker/Optional ABB
9.Operation & Maintenance manual
10.Special Integrated Steel Base tank and sprayed overall in gloss enamel paint
Note
Controller: Smartgen, Deepsea, ComAp, or Deif for optional
Alternator: Stamford, Leroy Somer, Marathon or Chinese top quality alternator for optional
Output range: 20kVA to 2500kVA with brand new diesel engine generator set
Generator set type: Open-type, soundproof type or mobile type for optional
Voltage available:380 -400-415V/220-230-240V for 50HZ; 220-380-416-440-480V/110-208-220-240V for 60HZ
We can design the diesel generator set as clients' requirement!
Product Specification
| SET |
Rated power(KW/kVA) |
25/31.25 |
| Frequency(Hz) |
50 |
| Pahse |
3 |
| Voltage(V) |
230/400 |
| Fuel capacity(L) |
280 |
| Fuel consumption(L/Hour) |
22 |
| Dimension (mm) |
L |
1700 |
| |
W |
800 |
| |
H |
1100 |
| Weight(KG) |
700 |
| Noice level for silent type (Db/7m) |
<100 |
| ENGINE |
Model |
4BT3.9-G2 |
| Prime power(kw/KVA) |
25/31.25 |
| Cylinders |
4 |
| Fuel consumtion(g/kw.h) |
210 |
| Intake Method |
Turbocharging |
| Displacement(L) |
3.92 |
| Speed governing |
Electronic governor |
| Cooling starting method |
Water cooling |
| ALTERNATOR |
Model |
KHI-25 |
| Rated power(kw/kva) |
25/31.25 |
| Insulation class |
H |
| Alternator enclosure |
IP23 |
Reference Photos
Sales Service
① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.
FAQ
Q1: What kinds of feed transport trailer I can order from your company?
A: We can supply various sizes of feed transport trailers from30-120tons,etc.
Q2: What's the fuel of your diesel generator?
A: We usually provide diesel and petroleum for customer's requirements.
Q3: What is your production standard of diesel generator? Whether your diesel generator been exported to USA, Canada and Europen countries?
A: Our diesel generator is produced as per China GB local standard; We can export diesel generator to those market, we ever exported diesel generator to Europen countries before.
Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
